Description
Heat Resistant Tape YS7023AJ, non stick adhesive tape working below 500F degrees.
- Heat Resistant Tape is using PTFE coated fiberglass fabric as basic material, and coated with Silicone pressure sensitive adhesive (PSA) on the back.
- The PTFE(Teflon)(Polytetrafluoroethylene) coating surface provides excellent release property, and the adhesive side will make sure the stable adhesion in high temperature below 260 degrees.
- Heat Resistant Tape has a yellow PVC liner on the back, which can protect the adhesive surface and to ease distinction and use.
- Youngsun(ESONE) can also cut the adhesive tape into any width, making small adhesive tapes for heat sealer machines, covering elements, impulse wires and L-Bar sealers.
Properties of Heat Resistant Tape YS7023AJ
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/cold-and-heat.jpg)
Outstanding temperature resistance (continuous working from -70°C to +260°C)
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/environment.jpg)
Perfect solution for tough environment transportation
![](https://www.tecidoptfe.com/wp-content/uploads/2022/05/ELEC.jpg)
Has strong dielectric strength
![](https://www.tecidoptfe.com/wp-content/uploads/2022/05/MECHA-.jpg)
Good mechanical strength, Excellent dimensional stability and durability in heat.
![](https://www.tecidoptfe.com/wp-content/uploads/2022/05/CHEMICAL.jpg)
High chemical resistant
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/Non-stick.jpg)
Superior non-stick surface, easy to release and clean
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/Long-life-time.jpg)
Offering long lasting easy release property
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/uv-resistance.jpg)
Resistance to UV
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/resist-RF-HF.jpg)
Resistance to HF and RF
Advantages of ESONE’s PTFE adhesive tape
Youngsun (ESONE) can customize tape according to the requirements of different applications.
- Custom adhesive — Silicone PSA or Acrylic adhesive
- Custom color — Color of PTFE fabric can be brown, black, white, red, blue, green and so on.
- Custom tensile strength — Tensile strength of adhesive tape can be enhanced for high request applications like wind turbine blades or manufacturing of composite aircraft components
![](https://www.tecidoptfe.com/wp-content/uploads/2023/03/Blue-PTFE-Tape.jpg)
Blue PTFE Tape
Specifications of Heat Resistant Tape YS7023AJ
Heat Resistant Tape maintains durability at high speeds and high temperatures while maintaining a long service life. Frequently used in heat sealers, blister formation and form-fill-seal equipment as well as lining of guide rails, chutes and slides. Acrylic adhesive is also available, although silicone adhesive is our standard.
Product | Product Category | Coating |
---|---|---|
PTFE GLASS FABRIC SELF ADHESIVE | STANDARD SERIE | SILICONE PSA |
Properties | Metric | Imperial |
---|---|---|
Standard width Please ask for other widths | 1000 mm | 39.5 inches |
Backing Thickness PTFE glass | 0.23 mm | 0.0091 inches |
Total Thickness PTFE glass and Silicone PSA | 0.28mm | 0.0111 inches |
Coated weight PTFE glass | 500 g/m² | 14.75 oz/yd² |
Tensile Strength PTFE glass | 420 N/cm Warp | 240 lbs/inches Warp |
360 N/cm Warp | 205 lbs/inches Warp | |
Adhesion | 5.8 N/cm | 52.6 oz/inches |
Temperature resistance | -73 to +260 °C | -94 to +500 °F |
Click here to download the TDS of YS7023AJ-ESONE
Contact us for more information and get samples!
