Introduction of PTFE Adhesive Fabric Industrial Series
High temp Teflon tape is also called as Self adhesive PTFE glass cloth tape. The basic material is high quality E-glass, and coated with high content PTFE (Teflon), after that, PTFE glass cloth was chemical treated on one side, so that the Silicone PSA or Acrylic Adhesive can be bonded on the fabric.
ESONE Teflon coated fiberglass tape is widely used in process like Lamination, Heat-pressing, Vulcanization, Drying, Dyeing or Printing, Insulation and so on. Since our Self Adhesive Teflon Tape has excellent non stick surface and can continuous working above 260 degrees.
Properties of High temp Teflon tape YS7008AJ
Outstanding temperature resistance (continuous working from -70°C to +260°C)
Perfect solution for tough environment transportation
Has strong dielectric strength
Continuous working below 260 degrees
High chemical resistant
Superior non-stick surface, easy to release and clean
Offering long lasting easy release property
Resistance to UV
Resistance to HF and RF
Application of Self Adhesive Teflon Tape
Aircraft Composites Manufacturing
ESONE PTFE coated fabric is used in the manufacturing of composite aircraft components, like mold release tape, vacuum bagging bleeder cloths.
Mold release tape is applied directly to the mold, allowing for a clean and easy release surface. And the porous PTFE fabric provides excellent release and is used as breather fabrics, allowing for air and volatiles to escape
Wind Turbine Blades Release
This application also use PTFE porous fabric and PTFE adhesive fabric. We customize PTFE porous fabric with balanced porosity & release property, and has high mechanical strength. For PTFE adhesive fabric, our mold release tape is easy release and has high mechanical strength, so that it can be reused many times easily.
Automotive Composites Manufacturing
-PTFE Release sheet for lightweight plastic/polymer processing like SMC, GMT and RMT.
-PTFE Release sheet for lightweight automotive components like front ends, underbody trims, door carrier, parcel shelf and auto seat.
-PTFE Release sheet with adhesive for vehicle cord fabric lamination.
-PTFE Bleeder cloths and PTFE mold release tape for carbon fiber car hood.
Electrical Insulation
Youngsun PTFE coated cloth is used for electrical insulation such as aerospace wire wrapping and electrical coil and phase insulation.-Our PTFE Fabric has excellent mechanical strength, high dielectric constant, strong chemical resistance and heat resistant to 500°F/260°C.
Youngsun PTFE fabrics are also used as linings for the coils of superconducting magnets in order for reducing noise and vibration.
FPCB CVL Lamination
Youngsun PTFE coated fabrics are used as release liner for CVL (coverlay) lamination or quick lamination, since our material has high mechanical strength and offers excellent release and non-stick property.
Excellent smooth, easy release and defect free PTFE fabric will maximum the output in FPCB manufacturing process.
Plastic bag manufacturing
Youngsun PTFE belting is used as conveyor belt to prevent polyethylene film sticking on the surface. Our belt last long, offers quick replace and easy to use.
Our belts for food packaging and sealing are available in tear resistant and porous versions for flexible packaging.
Packaging and Sealing
Youngsun PTFE belting is used as conveyor belt to prevent polyethylene film sticking on the surface. Our belt last long, offers quick replace and easy to use.
Our belts for food packaging and sealing are available in tear resistant and porous versions for flexible packaging.
PVC Window and Door welding
PTFE coated fiberglass cloth has excellent no stick surface and can resist heat up to 260°C, which can prevent melted PVC from sticking on welding platens. ESONE’s product is workable for all kinds of welding process, including RF and microwave systems.
Due to the non stick surface of PTFE Adhesive Sheet, ESONE product is used in Dyeing industry, in order for offering heat resistant and non stick surface.
Due to the non stick surface of PTFE Adhesive Sheet, ESONE product is used in Dyeing industry, in order for offering heat resistant and non stick surface.
Technical Data Sheet of Self Adhesive PTFE Tape
Product | Product Category | Coating |
---|---|---|
PTFE GLASS FABRIC SELF ADHESIVE | INDUSTRIAL SERIES | SILICONE PSA |
PTFE Adhesive Fabric Industrial Series | ||||||
---|---|---|---|---|---|---|
Style | Standard Width(mm) Please ask for other widths | Backing Thickness (mm) | Total Thickness (mm) | Weight (g/m2) | Adhesive (N/cm) | Tensile Strength Warp/Fill (N/cm) |
YS7010W-ESONE | 1000, 1250 | 0.10 | 0.15 | 200 | 5.4 | 240/200 |
YS7011A-ESONE | 1000, 1250 | 0.11 | 0.16 | 210 | 5.4 | 240/200 |
YS7011AJ-ESONE | 1000, 1250 | 0.11 | 0.16 | 220 | 5.4 | 240/200 |
YS7012AJ-ESONE | 1000, 1250 | 0.12 | 0.17 | 250 | 5.4 | 235/215 |
YS7023AJ-ESONE | 1000 | 0.23 | 0.28 | 500 | 5.8 | 420/360 |
Specification of PTFE adhesive tape
The normal size of self adhesive PTFE tape is 1 meter wide, 30m/50m/100m (or yard) long per roll, with yellow release liner for ease of application.
Or can be cut into small adhesive tape, with 12mm, 19mm, 25mm, 50mm, 75mm wide, 5m/10m/30m/50m long per roll, with or without yellow liner.
