Description
Teflon Sheet Adhesive YS7030AJ, long-lasting PTFE adhesive fabrics
- Teflon Sheet Adhesive YS7030AJ, with 0.35mm total thickness, has an easy release and long-lasting performance. The basic material is YS9030AJ, which has an excellent release surface and high mechanical strength, and the silicone pressure adhesive on the back is heat resistant and long-lasting.
- Teflon adhesive fabric has a yellow PVC liner on the back, which can protect the adhesive surface and ease distinction and use.
- Any width or length can be cut according to the applications, such as heat sealer machines, covering elements, impulse wires, L-Bar sealers, Wire wrap insulation, and harness protection.
Properties of Teflon Sheet Adhesive YS7030AJ
Outstanding temperature resistance (continuous working from -70°C to +260°C)
Perfect solution for tough environment transportation
Has strong dielectric strength
Continuous working below 260 degrees
High chemical resistant
Superior non-stick surface, easy to release and clean
Offering long lasting easy release property
Resistance to UV
Resistance to HF and RF
Specifications of Teflon Sheet Adhesive YS7030AJ
Normally, we sell 1000mm or 1250mm wide with a yellow release paper to protect adhesive. We can also supply short widths of 1″, 2″, etc width without release paper. Just use it as normal adhesive tape. Other Packing requirements are also workable, please contact us for details.
| Product | Product Category | Coating |
|---|---|---|
| PTFE GLASS FABRIC SELF ADHESIVE | PREMIUM SERIE | SILICONE PSA |
| Properties | Metric | Imperial |
|---|---|---|
| Standard width Please ask for other widths | 1000 mm | 39.5 inches |
| Backing Thickness PTFE glass | 0.30 mm | 0.0119 inches |
| Total Thickness PTFE glass and Silicone PSA | 0.35 mm | 0.0139 inches |
| Coated weight PTFE glass | 625 g/m² | 18.43 oz/yd² |
| Tensile Strength PTFE glass | 680 N/cm Warp | 389 lbs/inches Warp |
| 640 N/cm Warp | 366 lbs/inches Warp | |
| Adhesion | 6.2 N/cm | 57 oz/inches |
| Temperature resistance | -73 to +260 °C | -100 to +500 °F |
Esone PTFE Adhesive Packing
Contact us for more information and get samples！
Taixing, Jiangsu,China
Western End of South Third Ring Road
86-13901437262
Monday - Saturday from 8am - 5pm
sales@esone.com
sales@chinayoungsun.com
Contact us every time!
