Description
Silicone Adhesive Tape YS7011AJ, hot selling Industrial PTFE adhesive tape
- Silicone Adhesive Tape coated with PTFE, has anti-stick surface and heat resistant property, the basic construction is woven fiberglass fabric, which gives strong mechanical strength.
- This heat resistant and non stick adhesive tape allows for easy release, while making sure good mechanical strength and dimensional stability.
- ESONE Silicone adhesive tape is the product of choice where there is a request for continuous and efficient processing, offering superior initial tack, excellent bonding strength and long lasting performance up to 500˚F/260˚C.
Properties of Silicone adhesive tape
Outstanding temperature resistance (continuous working from -70°C to +260°C)
Perfect solution for tough environment transportation
Has strong dielectric strength
Good mechanical strength, Excellent dimensional stability and durability in heat.
High chemical resistant
Superior non-stick surface, easy to release and clean
Offering long lasting easy release property
Resistance to UV
Resistance to HF and RF
Regular size for Teflon adhesive tapes
Normal size is 1 meter wide, 30/50/100 meters long per roll, with yellow release liner.
Or can be cut into small roll, like 1.2cm, 2.5cm, 5cm, 7.5cm, 10cm wide and so on, 5m, 10m, 30m, 50m per roll.
Specifications of Silicone Adhesive Tape YS7011AJ
| Product | Product Category | Coating |
|---|---|---|
| PTFE GLASS FABRIC SELF ADHESIVE | INDUSTRIAL SERIES | SILICONE PSA |
| Properties | Metric | Imperial |
|---|---|---|
| Standard width Please ask for other widths | 1000, 1250 mm | 39.5, 49.3 inches |
| Backing Thickness PTFE glass | 0.11 mm | 0.0043 inches |
| Total Thickness PTFE glass and adhesive | 0.16 mm | 0.0063 inches |
| Baking weight PTFE glass | 220 g/m² | 6.5 oz/yd² |
| Tensile Stength PTFE glass | 240 N/cm Warp | 137 lbs/inches Warp |
| 200 N/cm Fill | 114 lbs/inches Fill | |
| Adhesion | 5.4 N/cm | 49 oz/inches |
| Temperature resistance | -73 to +260 °C | -100 to +500 °F |
Note:
- Thickness Tolerance mm= ±%5
- All technical data are based on average values.
- These values are based on test results we believes to be reliable.
