PTFE Coated Open Mesh Conveyor Belt

PTFE Coated Open Mesh Conveyor Belt

PTFE Coated Open Mesh Conveyor Belt, with a full range of open mesh belting products specifically for textile dryers. Our open mesh Belts are widely used for drying of screen Printed and dyed textiles at higher speed and higher temperature.

Teflon belt mesh sizes of 4X4 mm, 8×8 mm and 10×10 mm provide a high percentage of open surface area, creating maximum airflow and sufficient operation with minimum heat loss. Width and length stability of the belts are retain over full range of operating temperature.

Category:

Description

PTFE Coated Open Mesh Conveyor Belt, with a full range of open mesh belting products specifically for textile dryers. Our open mesh Belts are widely used for drying of screen Printed and dyed textiles at higher speed and higher temperature.

PTFE Coated Open Mesh Conveyor Belt, replacing steel conveyor belt

PTFE Coated Open Mesh Conveyor Belt, with a full range of open mesh belting products specifically for textile dryers. Our open mesh Belts are widely used for drying of screen Printed and dyed textiles at higher speed and higher temperature.

Teflon belt mesh sizes of 4X4 mm, 8×8 mm and 10×10 mm provide a high percentage of open surface area, creating maximum airflow and sufficient operation with minimum heat loss. Width and length stability of the belts are retain over full range of operating temperature.

Properties of Open mesh Teflon belt

Non-toxic and compliant for food applications, FDA & LFGB certificated
Operating temperature range from -70 to 260 degrees
Has strong dielectric strength Could be Anti-static
Any sizes could be made, the maximum width is 4m

Controlled porosity, different mesh size from 1mm to 10mm could be made

Exceptional strength and dimensional stability.
Great for architectural membrane
High chemical resistant
Light weight, easy to install
Resistance to HF and RF
Superior non-stick surface, easy to clean and release
Resistance to UV
Long lifetime

Properties of Open mesh Teflon belt

PTFE Glass – open mesh fabric series
StyleStandard Width(mm)
Please ask for other widths
Mesh Size
(mm)
Weight
(g/m2)
WeftColorTensile Strength Warp/Fill (N/cm)
YS6001-ESONE1000, 1500, 2050, 2600,2800, 3200,3650, 40001 x 1//Brown446/330
YS6002-ESONE1000, 1500, 2050, 2600,2800, 3200,3650, 40001 x 1//Black446/330
YS6003-ESONE1000, 1500, 2050, 2500,2750, 3200, 3350,3600, 40004 x 4460Single weftBlack320/434
YS6004-ESONE1000, 1500, 2050, 2500,2750, 3200, 3350,3600, 40004 x 4460Single weftBrown320/434
YS6008-ESONE1000, 1500, 1700, 2050,2500, 2700, 3200, 3400,3600, 3800, 40004 x 4580Double weftBrown360/500
YS6011-ESONE1000, 1500, 2500, 2700,3200, 3800, 40004 x 4580Double weftWhite330/470
YS6012-ESONE1000, 1500, 1700, 2050,2500, 2700, 3200, 3400,3600, 3800, 40004 x 4580Double weftBlack360/500
YS6013-ESONE1000, 1500, 2000, 300010 x 10//Brown220/360
YS6014-ESONE1000, 1500, 1800, 2000,3000, 36002 x 2.5//Black290/400
YS6015-ESONE1000, 1500, 1800, 2000,3000, 36002 x 2.5//Brown290/400
YS6016-ESONE1000, 1400, 2000, 28002 x 4//Brown330/470
YS6017-ESONE1000, 1500, 2000,
3600, 4000
5 x 5//Black320/434
YS6018-ESONE1000, 1400, 2000,28008 x 8//Brown350/480



 PTFE Glass – Stronger fiberglass series
StyleStandard Width(mm)
Please ask for other widths
Mesh Size
(mm)
Weight
(g/m2)
FiberglassWeftColorTensile Strength Warp/Fill (N/cm)
YS6001S-ESONE1000, 1500, 2000, 30001 x 1/Stronger fiberglass/Brown536/410
YS6008S-ESONE1000, 1400, 2500, 2600,2700, 3300, 3400, 3700,3800, 40004 x 4720Stronger fiberglassDouble weftBrown390/580
YS6008S-S-ESONE1000, 1350, 27004 x 41180Stronger fiberglassDouble weftBrown480/940
YS6016S-ESONE1000, 1700, 1800, 1900, 2400, 2600, 2800, 3400, 3600, 38002 x 4/Stronger fiberglass/Brown410/590
YS6030-ESONE1000, 1500, 1700, 2050,2700, 3200, 3400,3600,3800, 40002 x 2660Stronger fiberglassTriple weftBrown680/620
YS6031-ESONE1000, 1500, 2050, 2700,3200, 3600, 3800, 40002 x 2660Stronger fiberglassTriple weftBlack680/620
YS6032-ESONE1000, 1500, 2050, 2700,3200, 40002 x 2660Stronger fiberglassTriple weftRed680/620



 PTFE Kevlar/Glass – Kevlar/Glass series
StyleStandard Width(mm)
Please ask for other widths
Mesh Size
(mm)
Warp/WeftColorTensile Strength Warp/Fill (N/cm)
YS6007 Kevlar-ESONE1000, 1700, 2000, 2700,3400, 40004 x 4Kevlar/GlassBrown380/900
YS6200Bullnose Joint-ESONE120, 150, 170, 190, 210,250, 3004 x 4Kevlar/GlassBrown/
YS6201Bullnose Joint-ESONE120, 150, 170, 190, 210,250, 3004 x 4Kevlar/GlassBlack/

Applications of PTFE Coated Open Mesh Conveyor Belt

-Drying machine for non-woven textile, textile printing, silk-printing and dyeing machine.

-Shrinking machine for garment fabric, high-frequency and UV dryer.

-Conveyor belt for hot-air dryer, various of food baking, quick-frozen machines.

-Oiling machine for paper glazing and waxing, plant engineering. -Separating sheet for hardboard production etc.

-Release mesh for laminated glass vacuum bag

-Grill mesh for non stick and easy clean BBQ grilling

Different splices & joint & edge reinforcement

  • ESONE is not only offering the full range of PTFE mesh fabric, but also providing any kinds of splices & joints & edge reinforcement.
  • To enhance the tracking and belt life, ESONE offers various styles of edging:
  • PTFE film Edge Reinforcement (Heat-Sealed)
  • PTFE-Glass Edge Reinforcement (Heat-Sealed)
  • PTFE-Kevlar Edge Reinforcement (Heat-Sealed)
  • To assure the best performance and accurate tracking, we recommend that wherever possible, conveyor belts be ordered with splices.
  • We offer all the standard splices. Please call our technical service department to discuss which splice would be best for your specific application.
  • Overlap splice  Butt splice  Alligator/Clipping splice Castellated Splice Bullnose Splice
  PTFE Mesh Belt
Belt MaterialPTFE glass fabricPTFE Kevlar fabric
Belt JointBullnoseAlligatorPlastic
Belt EdgePTFE glass edgePTFE film edgePTFE Kevlar edge
Belt GuidePTFE guideKevlar guideSilicone guide
Belt PinStainless Steel PinPTFE PinAlligator Pin

Applications of Teflon open mesh belt

Release sheet for laminated glass manufacturing

ESONE high quality PTFE open mesh fabric is used as the release liner for laminated glass manufacturing.

The reason why use Teflon mesh is as follows.

1)  PTFE open mesh fabric is non stick

2)  Teflon net is porosity, the production can be vacuumized easily.

3)  Mesh PTFE fabric has high mechanical strength, has long lifetime.

Drying belt with high mechanical strength

Drying belt is the most common applications for PTFE mesh fabric.

Teflon open mesh belt can be easily found in food packaging, seafood processing, screen printing, pets food manufacturing, non woven manufacturing and many other applications

And Teflon open mesh belt which using strong fiberglass yarn has stronger mechanical strength and longer lasting property.

Teflon open mesh belt for non woven manufacturing

The heat resistant and non stick PTFE coated belt, is the critical feature of the thermal bonding process of non woven manufacturing.

During the drying process, the cotton with or without glue, the fiber with low melting point need to be dried and cured, then a PTFE mesh belt or PTFE heavy duty belt will be needed.

Conveyor belt for digital printing

Digital printing is a modern way to print pattern, different from traditional printing, digital printing minimize the printing cost and speed up the printing time.

PTFE mesh conveyor belt is used in the digital printing and drying, since PTFE mesh belt is Non stick, heat resistant, easy to install and cost-effective.

Contact us for more information and get samples!
