Description
Adhesive Backed Teflon Tape, made of woven fiberglass fabric coated with PTFE(Teflon) on both sides, and coated with Silicone pressure sensitive adhesive or Acrylic adhesive on the back.
Adhesive Backed Teflon Tape YS7011BJ, excellent release tape with heat resistant adhesive
Adhesive Backed Teflon Tape, made of woven fiberglass fabric coated with PTFE(Teflon) on both sides, and coated with Silicone pressure sensitive adhesive or Acrylic adhesive on the back. Which provides an excellent release surface and heat resistant adhesive, especially for applications which requiring high temperature, good electrical strength, mechanical strength and cost effectiveness.
Properties of High temp Teflon tape YS7008AJ
Has strong dielectric strength
Outstanding temperature resistance (continuous working from -70°C to +260°C)
Perfect solution for tough environment transportation
Good mechanical strength, Excellent dimensional stability and durability in heat.
High chemical resistant
Superior non-stick surface, easy to release and clean
Offering long lasting easy release property
Resistance to UV
Resistance to HF and RF
Specifications of Adhesive Backed Teflon Tape YS7011BJ
- Self adhesive PTFE fabric can be supplied as log rolls or slit tapes.
- Standard roll length is 30 meters or 50 meters, and standard width is 1000 mm, 1250mm upon special request.
- Yellow PVC release liner is used to protect the adhesive back, and ease the using ways. Adhesive Backed Teflon Tape can also be offered without release liner.
- Applications of self adhesive PTFE coated fabric, including easy release tape on heat sealing and packaging machines, ironing and pressing equipment, covering drying cylinders, lining chutes, release surface on bonding tools.
| Product | Product Category | Coating |
|---|---|---|
| PTFE GLASS FABRIC SELF ADHESIVE | INDUSTRIAL SERIES | SILICONE PSA |
| Properties | Metric | Imperial |
|---|---|---|
| Standard width Please ask for other widths | 1000, 1250 mm | 39.5, 49.3 inches |
| Backing Thickness PTFE glass | 0.11 mm | 0.0043 inches |
| Total Thickness PTFE glass and adhesive | 0.16 mm | 0.0063 inches |
| Baking weight PTFE glass | 220 g/m² | 6.5 oz/yd² |
| Tensile Stength PTFE glass | 240 N/cm Warp | 137 lbs/inches Warp |
| 200 N/cm Fill | 114 lbs/inches Fill | |
| Adhesion | 5.4 N/5cm | 49 oz/inches |
| Surface resistance | 10^7 to 10^5 OHMS/m² | 10^7 to 10^5 OHMS/m² |
| Temperature resistance | -73 to +260 °C | -100 to +500 °F |
