Description
Silicone Coated Fabrics for removable insulation jacket
- Silicone coated fabrics are fiberglass fabric impregnated with specially formulated silicone rubber. This silicone fabric can continuous working below 500F, and the flame retardant silicone rubber offer longer lifetime and increase the abrasion resistance, tear resistance and flexibility.
- Unlike PTFE impregnated fabric, silicone fabric is more flexible and cost effective, it has more choice for the coated color also.
Properties of 17oz Grey Silicone Coated Fabrics
Resistance to UV
High chemical resistant
Flame resistant and low smoke
Excellent dimensional stability, strong tensile strength and tear strength
Outstanding temperature resistance (continuous working from -70°C to +260°C)
Superior dielectric strength, strong resistance to electric arc
Environmental & Water & Oil resistant
Can be easily sewn
Easy to fabricate
long life time
Resistance to HF and RF
By using a specially formulated wet or dry silicone rubber, and specialized weaved satin fiberglass fabric, ESONE silicone coated fabric and textile can not only offer superior heat protection, but also has exceptional durability and high resistance to abrasion and chemicals.
★ Flexible for ease of use in pad fabrication
★ Available in a variety of thicknesses and colors
Applications of 17oz grey Silicone fiberglass
- Silicone coated fabrics provide high property of chemical, abrasion, heat, water and oil resistant, and is flexibility, also durability.
- Industrial applications of ESONE silicone/PTFE coating fabrics and textiles, including thermal insulation jackets, welding curtain, expansion joint, flame resistant curtains and so on.
- Most of our standard Silicone coated fiberglass cloth is used in industries such as welding, insulation, aerospace, automotive and petrochemical. And our engineer will adjust the formula, or using special fabric like Kevlar®, Nomex®, Nylon, Carbon, aramid blends, in order to meet the request of customer in different industries.
Pump Insulation Covers
Pump Insulation Covers
It is the perfect solution for industry like following：
★ Removable insulation blanket
★ Welding curtains
★ Expansion joints
★ fire protection curtains
★ anti-corrosion sector
★ Equipment covers
★ Safety clothing
★ Shrink tunnels
★ Foam manufacturing
Specifications of 17oz grey Silicone fiberglass
| Product | Product Category | Coating |
|---|---|---|
| SILICONE RUBBER COATED GLASS FABRIC | SILICONE BOTH SIDE | SILICONE RUBBER |
| 17 oz Silicone Impregnated Fiberglass Fabric YS5038 | ||
|---|---|---|
| Properties | Metric | Imperial |
| Basic Fabric | Satin weaved fiberglass | Satin weaved fiberglass |
| Coating | Both side | Both side |
| Standard width Please ask for other widths | 1500 mm | 60 inches |
| Coated Weight | 580 g/m² | 17 oz/yd² |
| Thickness | 0.38 mm | 0.015 inches |
| Tensile strength | Warp 2580 N/5cm | 295 lbs/inches |
| Fill 2100 N/5cm | 240 lbs/inches | |
| Mullen Burst | 420 N/cm² | 600 psi |
| Flame Resistant | Char Length 0.76 cm max | Char Length 0.3 inch max |
| Afterglow 1 second max | Afterglow 1 second max | |
| Flame Out 1 second max | Flame Out 1 second max | |
| Temperature resistance | -73 to +260 °C | -100 to 500 °F |
| UV Resistance | 1000 hours; no change in tensile | 1000 hours; no change in tensile |
| Color | Gray/White/Yellow/Black/Red/Silver | Gray/White/Yellow/Black/Red/Silver |
Contact us for more information and get samples！
